Robust and Modular Construction
Developer-Friendly Hardware Platform
Streamlined On-Site Maintenance
| Model | PIS-6 |
| Pixel Pitch (mm) | 6 |
| Module Resolution (HxW) | 16x23 |
| Module Size (HxW) (mm) | 96x193 |
| Font Height (mm) | 43 |
| Reading Distance (m) | 30~33 |
| Viewing Angle | 150° (110° for 50% luminance Angle) |
| LED | 3-in-1 SMD LED |
| Color | Full Color / Single Color |
| Luminance | > 5000 cd/m² |
| Working Temperature | -20°C ~ +45°C |
| Ingress Protection Class | IP65 |
| Brightness Control | Automatic / Manual / Schedule |
| Power Supply | 90 ~ 260VAC (50/60Hz) |
| Detection | Temperature, Humidity, Impact, Door-opened, Pixel Error |
Advanced Embedded Operating System
Comprehensive Development Environment
Remote Management and System Replication
| Model | PIS-5 |
| Pixel Pitch (mm) | 5 |
| Module Resolution (HxW) | 9x42 |
| Module Size (HxW) (mm) | 45x210 |
| Font Height (mm) | 35 |
| Reading Distance (m) | 16~18 |
| Distance Between Lines (mm) | 11.5 |
| Viewing Angle | 150° (110° for 50% luminance Angle) |
| LED | 3-in-1 SMD LED |
| Color | Single Color / Full Color |
| Luminance | > 5000 cd/m² |
| Working Temperature | -20°C ~ +45°C |
| Ingress Protection Class | IP55 |
| Brightness Control | Automatic / Manual / Schedule |
| Power Supply | 90 ~ 260VAC (50/60Hz) |
| Detection | Temperature, Humidity, Impact, Door-opened, Pixel Error |
